Place of Origin: | CHINA |
Brand Name: | TOBO |
Certification: | ISO |
Model Number: | / |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 51USD |
Packaging Details: | Usually bubble pack for each valve within carton box or plywood case, or special packaging upon customer requirements. |
Delivery Time: | 10-15DAYS |
Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram, Western Union |
Supply Ability: | 3000PCS/WEEK |
Port Size:: | DN40-DN1200 | Media: | Oil |
---|---|---|---|
Power:: | Pneumatic | Medium:: | Water,oil,gas |
Certification:: | 3A, SMS, DIN | Connection: | RF,FTJ,BW |
Seat Material: | TFM 4215 | Standard:: | API600 ASME B16.34 |
Temperature Range: | -20°C To 200°C @ 13 Bar Max | Applicable Temperature: | -40~+650℃ |
High Light: | DN40 Cast Steel Gate Valve,API600 Cast Steel Gate Valve,API600 Oil Gate Valve |
Motorised cast steel gate valve API600 for petrol oil
Industrial valves-Steel gate valves
1)ASME B16.34/API600/API6D
2"-48",Class150--Class1500
ASME/API600/API6D
Face to face to ANSIB16.10
Flanges drilled to ANSI B16.5
Body:A216WCB/WC6/WC9/LCB/LCC/CF8/CF8M
Trim:No.1/No.5/No.8,SS304/SS316
2) DIN/EN gate valves
Design and Manufacturer to DIN3352/BSEN1984
Flanges drilled to EN1092/DIN/ISO PN10-16-25-40-63-100
Body/bonnet/disc:Carbon Steel/Stainless steel
Seat:Carbon stee//Stainless steel/STL
Valve Size |
DN40-DN1500,2"-60" |
Connection |
Wafer,Lug,Flange,Buttweld |
Pressure rating |
Class150 Lb/Class300 Lb/Class600 Lb |
Operation |
lever,manual gear,pumatic,electric |
Body |
WCB/CF8/CF8M/CF3/CF3M/Monel/Hastelloy |
Stem |
17-4 PH/SS304/SS316/2Cr13 |
Disc |
CF8/CF8M/CF3/CF3M |
Seat |
PTFE/RPTFE/PPL |
BODY MATERIALS:As the body is internally fully rubber lined, the body material is protected from corrosion by the medium. |
|||
Type of material |
Material standard |
Example for application |
|
Ductile iron |
GGG40, DIN 1693 |
General application |
|
60-40-18,ASTM A536 |
|||
400-18, BS 2789 |
|||
Ductile iron(Heat treated) |
GGG40.3 DIN 1693 |
Heavy applications, Cold applications, petrochemical industries, power stations, alternative for cast steel |
|
Cast stainless steel |
CF8, ASTM A351 |
Medicine, food, drink |
|
CF8M, ASTM A351 |
|||
Bronze |
C-CuSn10Zn, DIN 1705(RG10) |
Marine service |
|
C90500, ASTM B584 |
|||
LG1, BS 1400 |
|||
|
|
|
|
DISC MATERIALS:As the disc is in direct contact with medium, the material should be carefully selected |
|||
Type of material |
Material standard |
Example for application |
|
Ductile iron nickel plated |
GGG40, DIN 1693 |
Air, non corrosive hot or cold water |
|
60-40-18,ASTM A536 |
|||
400-18, BS 2789 |
|||
Ductile iron nylon coated |
GGG40, DIN 1693 |
Potable water, water(max. 70°C, PH value between 4.5 and 9) |
|
60-40-18,ASTM A536 |
|||
400-18, BS 2789 |
|||
400-18, BS 2789 |
|||
Ductile iron, PTFE coated |
GGG40, DIN 1693 |
Acids, alkalis, oil, water, air |
|
60-40-18,ASTM A536 |
|||
400-18, BS 2789 |
|||
Cast stainless steel |
CF8M, ASTM A351 |
Potable water, demineralized water, solvents, industrial water, not recommended for sea water, gas |
|
Duplex stainless steel |
1.4462, EN 10088 |
Potable water, cooling water, sea water, demineralized water, solvents, foodstuff |
|
A181, Grade F51 |
|||
Aluminum bronze |
G-CuAl10Ni, DIN 1714 |
Sea water, potable water, gas |
|
C99500, ASTM B148 |
|||
AB2, BS 1400 |
|||
Hastelloy-C |
A494, CW-12MW |
Phosphoric, hypochloric, acetic, formic, sulfurous |
|
|
|
|
|
SHAFT MATERIALS:Materials for shafts are selected on the basic of disc materials |
|||
Type of material |
Material standard |
in combination with disc materials |
|
Stainless steel |
SS410 |
Stainless steel, ductile iron |
|
High strength stainless steel |
1Cr17Ni2 |
Stainless steel, ductile iron |
|
ASTM A431 |
|||
Stainless steel |
SS316 |
Stainless steel, ductile iron, aluminum bronze |
|
Aluminum bronze |
CuA10Ni5Fe4, DIN 17665 |
Aluminum bronze |
|
C63000, ASTM B150 |
|||
Monel |
NA18, BS 3076 |
Aluminum bronze(high pressure application) |
|
Hastelloy C276 |
ASTM B574, N10276 |
Hastelloy-C |
|
|
|
|
|
SEAT MATERIALS:It is essential for each individual case that the selection of the type of rubber complies with medium characteristics |
|||
Type of material |
Material standard |
Temp.range |
Example for application |
Nitrile rubber |
NBR |
0°C~90°C |
Aliphatic hydrocarbons(fuels, low aromatic containing oils, gasses), sea water, compressed air, powders, granular, vacuum, gas supply |
Ethylene-propylene rubber |
EPDM |
-20°C~110°C |
Water in general (hot-, cold-, sea-, ozone-, swimming-, industrial-, etc). Weak acids, weak salt solutions, alcohols, ketones, sour gasses, sugar juice |
Special ethylene-propylene rubber |
Special EPDM |
-10°C~70°C |
Potable water, foodstuffs, unchlorined drinking water |
Special ethylene-propylene rubber |
Special EPDM |
-30°C~120°C |
HVAC, chilled water, food stuffs & sugar juice |
Viton |
Viton |
0°C~200°C |
Many aliphatic, aromatic and halogen hydrocarbons, hot gasses, hot water, steam, inorganic acid, alkali |
Special viton |
Special viton |
0°C~130°C |
Concentrated acids |
PTFE |
PTFE |
10°C~155°C |
Fit for acids, alkalis, oil, not fit for low temperature |
|
|
|
|
NOTE:For use in fluids containing ammonia,all valve parts made from non copper containing materials. |
