EPDM Rubber Resilient Seated Gate Valve EN 1074-1 And 2 / EN 1171 Standard

Description:

Resilient seated NRS gate valve is a wedge gate valve and Non-rising stem type, and suitable for use with water and neutral liquids (sewage) . The non-rising stem design ensures the stem thread is adequately lubricated by the water passing through the valve.

Characteristic:

-On-line replacement of top seal: Easy installation and maintenance.

-Integral rubber-clad disc: The ductile iron frame work is thermal-clad integrally with high performance rubber. Ensuring tight seal and rust prevention.

-Integrated brass nut: By means of special casting process. the brass stem nut is integrated with the disc with secure connection, thus the products is safe and reliable.

-Flat-bottom seat: The sealing surface of the body is flat without hollow, avoiding any dirt deposit.

Application:

Water supply system, water treatment, sewage disposal, food processing, fire protection system, natural gas, liquefied gas system etc.

Resilient Seated Gate Valve Specifications:

Resilient Seated Gate Valve FEATURES

⊙ Shot-blasting

protective surface finished by shot-blasting and the surface is smooth and neatness.

⊙ Flatting seat

Smooth continuous bore way without seating recess, it is not easy to get impurity pilled up.

Making the liquid straightway.

⊙ Treating with rubber

Both inner and outer are coated with advanced knowledge of rubber vulcanization then making

sure of the elasticity of rubber ,and make sure the exact geometry dimension. Rubber and ductile

cast iron valve hand together hardly. This can avoid fall-off due to long-term use.

⊙ Three “○” sealed ring

With the three “O” – rings, the leakage can be greatly reduced and the “O” – ring can be

replaced under this condition with pressure and without stopping water. The thrust axletree

reduces the frictional resistance and lowers the operational torque. And it can be switch seal

ring without opening and closing.

⊙ Rigid round body

The body is founded minutely, the rigid geometry size ensure inner sealing of valve without

any process.

⊙ Light weight

This body is made of ductile iron, it is 20%-30% lighter than the olds. Easily to fixing and

servicing.

Applications : This valve widely applied in the liquid pipes for opening or closing fixing in such

water, sewage disposal, electric power, energetics pipe , chemical, shipping, energy sources etc.

Resilient Seated Gate Valve APPLICABLE STANDARDS

⊙ American Standard
Design to ANSI/AWWA C509
Face to face dimension to ASME B16.10-2000(ISO 3 series)
Flange and drilling To SME/ANSI B16.42-1998

⊙ British Standard
Design to BS5163,BS5150
Face to face dimension to BS5163(ISO 3series,ISO19 series)
Flange and drilling To BS4504 part1(EN1092)

⊙ Germany Standard
Design to DIN3352
Face to face dimension to DIN3202(F4:ISO 14 series;F5: ISO 15 series)
Flange and drilling to BS EN1092

Resilient Seated Gate Valve Specifications:

1.Products: DIN 3352 F4 DN600 Resilient Seated Gate Valve

2.Material Of Construction of the gate valve : Ductile Iron
3.Size of the gate valve: DN600

4.Working Pressure: PN10

5.Connection type: Flanged,DN2501,PN10
6.Seal Type: Soft seal(EPDM or NBR)

7.Design Standard:DIN3352

8.Face to face dimensions: DIN3202 F4

9.Each valve be tested according to test standard: DIN3230

10. Work Temperature: ≤80°C

11.Media:water

12.Stem type:Non rising stem

13.Length of valve: DIN3352 F4

14. Coating:blue powder epoxy

Resilient Seated Gate Valve FEATURES

⊙ Shot-blasting

protective surface finished by shot-blasting and the surface is smooth and neatness.

⊙ Flatting seat

Smooth continuous bore way without seating recess, it is not easy to get impurity pilled up.

Making the liquid straightway.

⊙ Treating with rubber

Both inner and outer are coated with advanced knowledge of rubber vulcanization then making

sure of the elasticity of rubber ,and make sure the exact geometry dimension. Rubber and ductile

cast iron valve hand together hardly. This can avoid fall-off due to long-term use.

⊙ Anti- corrosion

Both inner and outer are coated with non-toxic powder epoxy resin to strengthen the capacity of Corrosion resisting and raise the quality

of water supply.

⊙ Ruggedization

The older ductile iron valve is easy to rupture after being impacted by nonego. It can stop

rupture depend on the good mechanics capability of ductile iron .

⊙ Three “○” sealed ring

With the three “O” – rings, the leakage can be greatly reduced and the “O” – ring can be

replaced under this condition with pressure and without stopping water. The thrust axletree

reduces the frictional resistance and lowers the operational torque. And it can be switch seal

ring without opening and closing.

APPLICABLE STANDARDS

⊙ American Standard
Design to ANSI/AWWA C509
Face to face dimension to ASME B16.10-2000(ISO 3 series)
Flange and drilling To SME/ANSI B16.42-1998

⊙ British Standard
Design to BS5163,BS5150
Face to face dimension to BS5163(ISO 3series,ISO19 series)
Flange and drilling To BS4504 part1(EN1092)

⊙ Germany Standard
Design to DIN3352
Face to face dimension to DIN3202(F4:ISO 14 series;F5: ISO 15 series)
Flange and drilling to BS EN1092
