| Product Name: | Swing Check Valve | Material: | 316L |
|---|---|---|---|
| Application: | Oil, Gas, Water, Steam Etc | Advantage: | Quiet |
| Temperature: | -10~80 C | Design: | Wafer |
| Body: | Stainless Steel | Seat: | Stainless Steel |
| High Light: | Vertical Stainless Steel Ball Check Valve,Quiet Wafer Ball Check Valve,PN16 Ball Check Valve |
||
Vertical Stainless Steel Ball Check Valve One Way Corrosion Resistance
| Product Name: | Silence Check Valve | Application: | Water , Oil, Gas, Etc., |
|---|---|---|---|
| Size: | Size From ½” Up To 2” | Pressure: | PN16 |
| Connect: | BSP NPT | Temperature: | -10~80 C |
| Body: | Brass | Spring: | SS304 |
| High Light: |
stainless steel ball check valve,flanged ball check valve |
||
Vertical Stainless Steel Ball Check Valve One Way Corrosion Resistance
Ball Check Valve Introduction
1 Media: sea water, oil, liquefied gas,steam
2 Temperature: water below 120 degree C, oil ,gas ,steam below 220 degree C
3 Tread connection Std: (G ,Rc ,RP) BSP, BSPT ,NPT
Ball Check ValveFeatures
1 ) Light weight,convenient to transport and handle
2 ) High strength
3 ) less resistance
4 ) Corrosion resistance
5 ) No furring
6 ) Sound insulation
7 ) Easy to install
8 ) long lifespan
9 ) low cost
10 ) Hygienic harmless potable water installations
11 ) Recyclable:thereby benefiting the environment
12 ) Colors:Natural,other custom-made colors available
13 ) OEM/ODM welcome
14 ) Healthy and non -toxic,bacterial neutral .conforming to drinking water standards
15 ) Reliable installation,low construction expense
16 ) Good heat preservation
has been widely applied in pipe system of industry.
It can be installed in both vertical and horizontal direction, and the suitble media can be water, oil and gas, with the fetures of light weight, reliable seal function and good looking, it has been the first choice for more and more engineers.
| Material List | |||
| Part | Material | ASTM | BS |
| Body | Brass | B124 C38800 | 2874 CZ122 |
| Cap | Brass | B124 C38800 | 1400 LG2 |
| Disc | Brass | B124 C38800 | 2874 CZ122 |
| Spring | Stainless Steel | A313 304 | 3111 304S31 |
| Seat | NBR | ||
| Product Name | Brass vertical check valves Chinese manufacture with various size |
| Material | brass |
| Color | brass yellow |
| Standard | JIS ANSI |
| PRESSURE | PN16 |
| Valve Standard | Comply with MSS SP-80 Threaded to BS 21(ISO7)/ASME B1.20.1 |
|
| Size Range | 15mm (1/2") ~ 50 mm(2") | |
| Working pressure | 300psi (20.7 bar)WOG Non-Shock 150psi (10.3 bar)Saturated Steam |
|
| Testing Pressure | Shell: 450 psi(31 bar)Hydrostatic | |
| Seat: 330psi (22.7 bar) Hydrostatic 80 psi (5.5 bar) Air |
||
| Suitable Media | Water, Oil, Gas |
|
Part List / Materials of Construction
| Part | Description | Standard | Special |
| 1. | Body | Cast Iron | St. Steel, Cast Steel |
| 2. | Cover | Cast Iron | St. Steel, Cast Steel |
| 3. | Ball | Nitrile Reinforced | EPDM, Neoprene |
| 4. | Cover Ring | Nitrile Rubber | Butyle, Viton |
| 5. | Ball Seat Ring | L. T. Bronze | St. Steel, Hard Rub. |
| 6. | Fasteners | Carbon Steel | St. Steel |
Description:
| Technical Parameters | ||||
| Model | PN(MPa) | Casting test pressure(MPa) | Seal test pressure (MPa) | Materials of body, bonnet |
| HQ41X-10 | 1 | 1.5 | 1.1 | iron or steel |
| HQ41X-16 | 1.6 | 2.4 | 1.76 | |
| Mail part & material | ||||
| Body : Cast iron, ductile cast iron ,WCB | ||||
| Bonnet : Cast iron, ductile cast iron, WCB | ||||
| Ball : cast steel coated with neoprene | ||||
| Medium : water and weak corrosive fluid | ||||
| Dimensions | ||||||
| DN(mm) | L | D | D1 | D2 | Z-φd | H |
| 50 | 180 | 160 | 125 | 100 | 4-18 | 185 |
| 65 | 200 | 180 | 145 | 120 | 4-18 | 210 |
| 80 | 260 | 195 | 160 | 135 | 4-18/8-18 | 245 |
| 100 | 300 | 215 | 180 | 155 | 8-18 | 280 |
| 125 | 350 | 245 | 210 | 185 | 8-18 | 335 |
| 150 | 400 | 280 | 240 | 210 | 8-23 | 400 |
| 200 | 500 | 335 | 295 | 265 | 8-23/12-23 | 495 |
| 250 | 600 | 390/405 | 350/355 | 320 | 12-23/12-25 | 600 |
| 300 | 700 | 440/460 | 400/410 | 375 | 12-23/12-25 | 715 |
| 350 | 800 | 500/520 | 460/470 | 435 | 16-23/16-25 | 820 |
Check Valve - Ball type (nonreturn valve) was the first valves at with a unique design. A very simple
but robust design with no critical mechanism involved.
All parts like hinge pin disc mechanism used in conventional valve are eliminated, and has put in a
reinforced rubber coated ball to arrest flow media in return condition.
This ball, moves totally out of the flow path when the pumping is on to give minimum head losses.
The spherical rubber coated ball seals perfectly on the rounded valve seat ensuring a totally leak proof
sealing.
This design offers other advantages like non clogging & self cleaning. In this virtually maintenance free
valves, if required, after prolonged usage, the on-line replacement of the ball is just a minute job.
* Lower power consumption
* Larger solid handling capacity
* Self cleaning, Non-Clogging
* Perfect Sealing
* Low pressure drop
Principle:
The heart of this valve is a reinforced rubber ball. The unique design of the valve allows free movement of the ball.
The ball moves to open position when the pump starts & allows free flow of liquid without any interference (See Fig.).
As the pump stops, the ball seats firmly against the metal seat due to its own weight & back pressure of
the liquid (Mouse over fig.). This results in DROPLESS sealing.
Part List / Materials of Construction
| Part | Description | Standard | Special |
| 1. | Body | Cast Iron | St. Steel, Cast Steel |
| 2. | Cover | Cast Iron | St. Steel, Cast Steel |
| 3. | Ball | Nitrile Reinforced | EPDM, Neoprene |
| 4. | Cover Ring | Nitrile Rubber | Butyle, Viton |
| 5. | Ball Seat Ring | L. T. Bronze | St. Steel, Hard Rub. |
| 6. | Fasteners | Carbon Steel | St. Steel |
