Trunnion Mounted Ball Valve Carbon Steel 3" 300# 3 Way T Type Internal Thread Manual Operated

Trunnion Mounted Ball Valve Carbon Steel 3" 300# 3 Way T Type Internal Thread Manual Operated

Quick Details

trunnion mounted ball valves feature: a full line product offering with valves ranging in 2"-42", ANSI classes 150LB - 2500LB, forged steel bolted or all welded body, close coupled trunnion block design for low operating torques, secondary seat sealant feature.Kojo API-6D valves are offered with self relieving seats or optional double piston sealing. Special seat compounds are also available. Each valve meets, API-6D, API 6FA and Nace requirements. Options include stem extensions, actuators, pipe pups and specialized coatings.

Design Features

Trunnion mounted ball valves met all the requirements of API 6D as well as the other design codes;Minimum wall thickness comply with ASME B16.34. Valves are usually supplied with lever,gear box,actuator or bare shaft on customer request

1. ISO5211 platform design is adopted for the convenience of installing the actuator
2. Double block and bleed function
3. Anti-blow-out stem design
4. The pressure balancing hole is provided on the steel ball
5. The body is provided with a device for cleaning the valve cavity
6. Automatic pressure relief function
7. Fireproof and antistatic design
8. Sealant injection system for emergency seal
9. Multiple driving modes facilitate the realization of automatic control
10. Reliable stem seal and low operating torque. Metal hard seal seat can be made according to requirements

Standard

Design & Manufacturing Standard:API 608, API 6D, ASME B16.34,
Face to face:ASME B16.10 ,API 6D,DIN 3202
Flange Connection Size:ASME B16.5, ASME B16.47, DIN 2543～2550, ASME B16.25
Butt Welding Size:ASME B16.25.
Test and inspection: API 6D, API 598

A Ball valve is a quarter-turn rotary motion valve that uses a ball-shaped disk to stop or start the flow.

It resembles a plug valve in many ways. When a port in the ball is in line, it allows flow whereas when you

rotate the valve 90 degrees, solid part of the ball stop the flow.

Most ball valves are of the quick-acting type, which requires a 90° turn of the valve handle to operate the valve.

But in case large size valve which required considerable force to open or close the valve, the gear-operated

actuator is used. With this arrangement, a small handwheel is enough to operate a fairly large valve.

In this article, I have covered following types of Ball Valves that used in piping.

• Floating

• Trunnion Mounted

• 3 Way

• Top entry

• Side entry or split body

• Three-piece body

Applications of the Valve

• It can be used in different types of fluid services as an on-off stop valve that provides bubble-tight shutoff.

• It can be used in air, gaseous, and vapor services as well as hydrocarbon services.

• Metal seated valves can be used in high-pressure & temperature applications.

• it is widely used with instrument tubing to connect instruments.

Advantages

• It is quick to open and close type that provides bubble-tight reliable sealing in high-pressure temperature applications.

• It is smaller and lighter than a gate valve of the same size and rating.

• Several designs of ball valves offer the flexibility of selection so that you can choose the valve that suits your requirements.

• Easy to operate and Cost-effective maintenance.

Features:

1.Forged ball
2.Anti-fire safe design
3.Anti-static device
4.Free leakage of body Sealed construction
5.Low torque in operation
6.Double block&bleed(DBB)
7.Emergency sealing
8.Extension stem at your choice
9.Automatic body cavity relief
10.Various driving types: gear, lever, electric, hydraulic, pneumatic

Standards Compliance

Design and manufacture: ANSI B16.34, API 608, API 6D, BS5351
Face to face dimensions: ANSI B16.10, API 6D
Flanged connection: ANSI B16.5, ANSI B16.47
Butt welded: ANSI B16.25
Fie-safe: API 607, API 6FA
Test and inspection: API 598, API6D

Packaging Details

Valves are wrapped in plastic bubble sheet & in plywood boxes

Port:China

Lead Time :

Types of Ball Valves:

Although ball valves can be divided into many types based on the functionality, their major two categories are given below:

Floating Ball Valve:

A floating ball valve does not have any anchor for holding the ball. However, there is a stem that is attached to the ball.

Due to this reason the fluid freely moves the ball downwards according to the pressure of the flow. A floating ball valve

is considered a great choice for regulating the flow of the valve.

Trunnion Ball Valve:

Unlike the floating ball valve, trunnion ball valve comes with an anchor on both sides of the ball. This additional support

provides pivot to the ball and helps contain the huge flow. Due to this reason, trunnion ball valves are very popular for the

applications, which involve the flow of high-pressure valves.
