TOBO STEEL GROUP CHINA
 |
| Place of Origin: | CHINA |
| Brand Name: | TOBO |
| Certification: | ISO |
| Model Number: | Floating Ball Valve |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | Valves are wrapped in plastic bubble sheet & in plywood boxes |
| Delivery Time: | 15-20 DAYS |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000PCS |
| Product Name: | Floating Ball Valve | Material: | SS316 |
|---|---|---|---|
| Presure: | 1,000/800psi | Size: | DN65 |
| Usage: | Oil And Gas | Temperature Of Media: | High-Pressure Temperature |
| Packaging Details: | Valves Are Wrapped In Plastic Bubble Sheet | Temperature: | -20 To 425°C |
| High Light: | Full Welded SS Ball Float Valve,Flanged Type Ball Float Valve,800psi Ball Float Valve |
||
Full Welded Ss Ball Float Valve , Flanged Type Ball Float Vent Valve
| Product Name: | Ss Ball Float Valve | Application: | Oil, Gas Etc., |
|---|---|---|---|
| Size: | DN15 ~DN250 | Pressure: | PN16 / 150lbs |
| Type: | Full Welded | Temperature: | -20~429 C |
| Body: | Stainless Steel Body | Ball: | Stainless Steel/ SS304/SS316/SS201 |
| High Light: |
flanged ball valves,stainless steel ball float valve |
||
Full Welded Ss Ball Float Valve , Flanged Type Ball Float Vent Valve
Ss Ball Float Valve :
W.N.R.F. Flanged Ball Valves, Full bore, lever operated, ANSI Class 150/300. Dimensions
API 6D and, tests to API with following parameters:
Body Material : ASTM A216 WCB
Ball and Trim Material : Stainless Steel
Lever Material : Forged steel with Zn coated
Seat Material : PTFE
Working Temperature : 05°C to 50°C
Working Pressure : 150 Psig./350 Psig.
Fluid to be handled : Natural Gas
(Odorized) containing 0.5% CO2 by volume.
Ss Ball Float Valve Introduction
1) Ball Valve (1" ) DN25,2pc-Flanged /Hose Ball Valve ,Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,Working Temperatures (-29C to +427C)
2) Ball Valve ( 1 1/4" ) DN25,2pc-Flanged /Hose Ball Valve, Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,Working Temperatures (-29C to +427C)
3) Ball Valve (3/4" ) DN25,2pc-Flanged /Hose Ball Valve, Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,Working Temperatures (-29C to +427C)
Ss Ball Float Valve Description:
The ball valve is designed and manufactured according well to API 608. Floating ball when small caliber,
and fixed ball when large caliber.
It has fire protection structure and antistatic device. Widely used for petroleum, chemistry, water
treatment industries.
Ss Ball Float Valve Features:
-Prompt switch
The ball valve circumrotates in 90°,It work quickly to open or close.
|
Test Pressure
Main Connection Dimensions
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Type | Size(mm) | Dimension(mm) | ||||||||
| inch | DN | L | D | D1 | D2 | b | Z-Φd | H | W | |
| Q41F/H/Y-300Lb Q341F/H/Y-300Lb Q641F/H/Y-300LbY |
1/2″ | 15 | 140 | 95 | 66.5 | 35 | 15 | 4-Φ15 | 72 | 115 |
| 3/4″ | 20 | 152 | 117 | 82.5 | 43 | 16 | 4-Φ19 | 75 | 130 | |
| 1″ | 25 | 165 | 124 | 89 | 51 | 18 | 4-Φ19 | 85 | 150 | |
| 11/4″ | 32 | 178 | 133 | 98.5 | 64 | 19.5 | 4-Φ19 | 95 | 180 | |
| 11/2″ | 40 | 190 | 156 | 114.3 | 73.2 | 21 | 4-Φ22 | 110 | 230 | |
| 2″ | 50 | 216 | 165 | 127 | 92 | 23 | 8-Φ19 | 120 | 240 | |
| 21/2″ | 65 | 241 | 190.5 | 149.4 | 104.7 | 26 | 8-Φ22 | 150 | 280 | |
| 3″ | 80 | 283 | 210 | 168.5 | 127 | 29 | 8-Φ22 | 165 | 310 | |
| 4″ | 100 | 305 | 254 | 200.2 | 157 | 32 | 8-Φ22 | 190 | 330 | |
| 5″ | 125 | 381 | 279 | 235 | 185.7 | 35 | 8-Φ22 | 240 | 600 | |
| 6″ | 150 | 403 | 318 | 270 | 216 | 37 | 12-Φ22 | 270 | 800 | |
| 8″ | 200 | 502 | 381 | 330 | 270 | 42 | 12-Φ25 | 315 | 1000 | |
| 10″ | 250 | 568 | 445 | 387.5 | 324 | 48 | 16-Φ29 | 380 | 1200 | |
| Type | Size(mm) | Dimension(mm) | ||||||||
| inch | DN | L | D | D1 | D2 | b | Z-Φd | H | W | |
| Q41F/H/Y-600Lb Q341F/H/Y-600Lb Q641F/H/Y-600Lb |
1/2″ | 15 | 165 | 95 | 66.5 | 35 | 15 | 4-Φ15 | 88 | 115 |
| 3/4″ | 20 | 190 | 118 | 82.5 | 43 | 16 | 4-Φ19 | 98 | 130 | |
| 1″ | 25 | 216 | 124 | 89 | 51 | 18 | 4-Φ19 | 105 | 150 | |
| 11/2″ | 40 | 241 | 156 | 114.3 | 73.2 | 23 | 4-Φ22 | 135 | 180 | |
| 2″ | 50 | 292 | 165 | 127 | 92 | 26 | 8-Φ19 | 155 | 240 | |
| 3″ | 80 | 356 | 210 | 168.2 | 127 | 32 | 8-Φ22 | 175 | 280 | |
| 4″ | 100 | 432 | 273 | 216 | 157 | 38 | 8-Φ25 | 210 | 330 | |
| 6″ | 150 | 559 | 356 | 292 | 216 | 48 | 12-Φ29 | 340 | 800 | |
| 8″ | 200 | 660 | 419 | 349 | 270 | 56 | 12-Φ32 | 400 | 1000 | |
| 10″ | 250 | 787 | 508 | 432 | 324 | 64 | 16-Φ35 | 440 |
1200 |
|
Forged Ball Valve Feature:
- Anti-blowout Structure of Valve Stem
When medium pass through the valve, the pressure in valve body may possibly
push the stem out, or when the valve is in repair, if there is pressure in the middle
cavity, the stem or medium seems to easily fly out upon disassembling the valve,
which can cause injures to human beings,
To prevent the possibilities, a dummy club is packing and thrust bearing are burnt
or packing is damaged due to other causes, the pressure of medium in valve body
will make the dummy club of valve stem in close contact with the upper seal face of
valve body.
Thus to prevent medium leaking out from the damage packing position.
- Reliable Seal Structure
The seat is made of PTFE. Because the contact area between seat and the ball will
becomes more high with rising of pressure of the middle cavity,
Small Resistance ball valve has the smallest resistance of all the valve, in the case
of reduced bore, the resistance is little still.
Floating Ball Valve Main part & material
| Part name | Material |
| body | WCB,ZG1Cr18Ni9Ti,CF8 |
| ball | 1Cr18Ni9Ti 304,316 |
| stem | 1Cr18Ni9Ti 304,316 |
| seal ring | Polytetrafluoroethlene(PTFE) |
| packing | Polytetrafluoroethlene(PTFE) |
| DN | G | B | L | E | H | A |
| 6 | 1/4" | 8 | 54 | 11.5 | 52 | 105 |
| 10 | 3/8" | 10 | 54 | 11.5 | 52 | 105 |
| 15 | 1/2" | 15 | 62.5 | 14 | 65 | 130 |
| 20 | 3/4" | 20 | 73.5 | 15 | 70 | 130 |
| 25 | 1" | 25 | 86 | 15 | 78 | 150 |
| 32 | 1-1/4" | 32 | 101 | 18 | 82 | 180 |
| 40 | 1-1/2" | 38 | 110 | 19 | 90 | 200 |
| 50 | 2" | 50 | 123 | 19 | 98 | 200 |
| 65 | 2-1/2" | 64 | 165 | 23 | 140 | 240 |
| 80 | 3" | 80 | 190 | 25 | 135 | 260 |
Technical Specification
| Nominal pressure(Mpa) | PN | 2.5,4.0,6.4 |
| Strength testing pressure(Mpa) | PT | 3.8,6.0,9.6 |
| Low pressure seal test(Mpa) | 0.6 | |
| High pressure seal test(Mpa) | 3.0,4.8,7.6 | |
| Applicable medium | water, oil, gas, nitric acid, acetic acid | |
| Applicable temperature | -40～180℃ | |
Feature:
- Anti-blowout Structure of Valve Stem
When medium pass through the valve, the pressure in valve body may possibly
push the stem out, or when the valve is in repair, if there is pressure in the middle
cavity, the stem or medium seems to easily fly out upon disassembling the valve,
which can cause injures to human beings,
To prevent the possibilities, a dummy club is packing and thrust bearing are burnt
or packing is damaged due to other causes, the pressure of medium in valve body
will make the dummy club of valve stem in close contact with the upper seal face of
valve body.
Thus to prevent medium leaking out from the damage packing position.
- Reliable Seal Structure
The seat is made of PTFE. Because the contact area between seat and the ball will
becomes more high with rising of pressure of the middle cavity,
Small Resistance ball valve has the smallest resistance of all the valve, in the case
of reduced bore, the resistance is little still.
- Prompt switch
The ball valve circumrotates in 90°,It work quickly to open or close.
Specifications:
Technical Specification
- Nominal diameter: 1/2”-25”
- Applicable Temperature: -29℃～425℃(steel) -40℃～550℃(stainless steel)
- Nominal pressure: 150lbs, 300lbs, 600Lb,900lbs,1500lbs PN16/25/40/64/100/160, JIS 5K /10K/20K
- Applicable Medium: water ,gas,oil,and other causticity medium.
Floating Ball Valve Features:
- Anti-blowout Structure of Valve Stem
When medium pass through the valve, the pressure in valve body may possibly push the stem out, or
when the valve is in repair, if there is pressure in the middle cavity, the stem or medium seems to easily
fly out upon disassembling the valve, which can cause injures to human beings, To prevent the
possibilities, a dummy club is packing and thrust bearing are burnt or packing is damaged due to other
causes, the pressure of medium in valve body will make the dummy club of valve stem in close contact
with the upper seal face of valve body. Thus to prevent medium leaking out from the damage packing
position.
- Reliable Seal Structure
The seat is made of PTFE. Because the contact area between seat and the ball will becomes more high
with rising of pressure of the middle cavity, Small Resistance ball valve has the smallest resistance of all
the valve, in the case of reduced bore, the resistance is little still.
-Prompt switch
The ball valve circumrotates in 90°,It work quickly to open or close.
|
Test Pressure
Main Connection Dimensions
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
