Detailed Product Description
Production Name: Flanged End Globe Valve Material: SS304
Ends: Flanged Ends Or Threaded Application: Gas,Oil,Water, Corrosie Liquid And Steam
Size: DN80 Pressure: PN16
Tempreture: High Temperature Stem Thread Position: Outside Screw Stem Globe Valve
High Light:

Copper Alloy Water Globe Valve

,

1/2" Globe Valve

,

300LBS Globe Valve

Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT

Detailed Product Description
Product Name: STOPCOCK Application: Oil, Gas, Water, Steam Etc.,
DN: 1/4"~2" Pressure: PN16 /150lbs /JIS 10K
Standard: API 6D/ ANSI 16.5 B/ JIS 20K/JIS 10K Temperature: -29~425 C
Body: Brass/ Chromed Stem: Stainless Steel/ 2Cr13
High Light:

cast steel globe valve

,

water globe valve





Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT




STEM PACKING GLAND,

HAND WHEEL,

WITH STOP COSK:

GLOBE PATTERN TYPE WITH SOFT SEALING WASHER (RUBBER OR ),

COPPER ALLOY BODY,

NPT SCREWED FEMALE ENDS,

SCREWED BONNET AND STEM PACKING GLAND,

WATER SERVICE ONLY,

WORKING PRESSURE 250 PSI,

TEST PRESSURE: 300 PSI,

TEST CERTIFICATES AND MARKINGS INCLUDING SIZE AND PRESSURE RATING REQUIRED

SIZE IN INCHES: 1/2

BODY MATERIAL: COPPER ALLOY

TYPE: STOP COCK

SIZE IN INCHES: 1/2

CONFIGURATION: GLOBE

DESIGN RATING: 250 LBS WP, 300 LBS TEST

END CONNECTION: FNPT

STYLE: STEM PACKING GLAND

OPERATION: HANDWHEEL

GLAND PACKING: WITH SOFT SEALING WASHER (RUBBER OR )

STEM DESIGN: NON-RISING STEM

PATTERN: GLOBE PATTERN TYPE

BONNET CONSTRUCTION: SCREWED BONNET

SERVICE: WATER SERVICE

TRIM MATERIAL: COPPER ALLOY

MATERIAL & TEST CERTIFICATE:SUPPORTED



Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT 0















GLOBE VALVE, FLANGED TO A.S.A B16.5 SUITABLE FOR SOUR GAS SERVICE



selection of possible applications:
(industry) (power station)
(flue gas puerification plant) (gas supply)
(vacuum facilities) (ammonia)
(hot water) (cllling&freezing systme)
(heating technology) (steam system)



The globe valve is designed reference to advanced internal and international standard.Adopting different material, the valve may works with different medium, such as water,oil,gas,steam,carbamide and other medium.







Features
Outside Screw and Yoke (OS & Y), Rising Stem
Bolted Bonnet
Conic Disc
Extended Bonnet for Cryogenic Services
Impact hand wheel optional
Gear Optional
Specifications
Design: ASME B16.34/BS 1873
Face to Face: ASME B16.10
End to End: ASME B16.10
End Flange: ASME B16.5
BW End: ASME B16.25
Test: API 598
Special: NACE MR-01-75

Notes:The size of serial,valve connecting flange can be design according to customers reguirment.



Products performance specification



Parts Materials
Body ASTM A216 GR.WCB
Seat Ring ASTM A105 + Stellite Faced
Disc ASTM A105 + 13Cr Faced
Disc Thrust Plate ASTM A276 Type 420
Disc Nut ASTM A276 Type 410
Stem ASTM A182 GR.F6
Bonnet Bolt Nuts ASTM A194 GR.2H
Bonnet Bolts ASTM A193 GR.B7
Gasket Soft Iron + Graphite
Backseat Bushing ASTM A276 Type 410
Stem Packing Braided Graphite & Die formed Graphite Ring
Bonnet ASTM A216 GR.WCB
Eyebolt Pins Carbon Steel
Gland ASTM A276 Type 410
Gland Flange ASTM A216 GR.WCB
Gland Eye Bolts ASTM A307 GR.B
Eyebolt Nuts ASTM A194 GR.2H
Yoke Bush ASTM A439 GR.D-2
Screw Carbon Steel
Hand Wheel Ductile Iron
Hand Wheel Nut ASTM A194 GR.2H
Washer Carbon Steel
Yoke ASTM A216 GR.WCB
Yoke Pan Bolt Nuts ASTM A194 GR.2H
Yoke Pan Bolt ASTM A193 GR.B7
Bearing Steel
Lantern Ring On Request ASTM A276 Type 410

Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT 1 Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT 2 Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT 3



Main Dimensions



ASME Pressure Class 150 Lb-Dimensions and Weights


NPS in 2 2.5 3 4 5 6 8 10 12 14 16
d mm 51 64 76 102 127 152 203 254 305 337 387
L-L1 in 8 8.5 9.5 11.5 14 16 19.5 24.5 27.5 31 36
(RF-BW) mm 203 216 241 292 356 406 495 622 698 787 914
L2 in 8.5 9 10 12 14.5 16.5 20 25 28 31.5 36.5
(RTJ) mm 216 229 254 305 368 419 508 635 711 800 927
H in 13.43 14.45 14.76 19.02 21.14 20.35 23.23 29.69 37.05 42.72 38.03
(open) mm 341 367 375 483 537 517 590 754 941 1085 966
W in 7.87 9.84 9.84 11.81 11.81 13.78 15.75 17.72 25.2 25.2 18.11
mm 200 250 250 300 300 350 400 450 640 640 460
WT BF 22 29 42 64 77 105 154 288 507 617 810
(Kg) BW 19 25 34 49 65 82 131 249 430 580 763



ASME Pressure Class 300 Lb-Dimensions and Weights

NPS in 2 2.5 3 4 5 6 8 10 12
d mm 51 64 76 102 127 152 203 254 305
L-L1 in 10.5 11.5 12.5 14 15.75 17.5 22 24.5 28
(RF-BW) mm 267 292 318 356 400 444 559 622 711
L2 in 11.12 12.12 13.12 14.62 16.37 18.12 22.62 25.12 28.62
(RTJ) mm 283 308 333 371 416 460 575 638 727
H in 13.74 14.8 16.93 19.13 22.05 24.33 36.89 37.36 39.17
(open) mm 349 376 430 486 560 618 937 949 995
W in 7.87 9.84 9.84 13.78 15.75 17.72 2.05 25.2 18.11
mm 200 250 250 350 400 450 560 640 460
WT BF 31 43 57 86 130 168 280 385 724
(Kg) BW 26 38 44 68 110 138 228 329 618



ASME Pressure Class 300 Lb-Dimensions and Weights



NPS in 2 2.5 3 4 6 8 10 12
d mm 51 64 76 102 152 200 248 298
L-L1 in 11.5 13 14 17 22 26 31 33
(RF-BW) mm 292 330 356 432 559 660 787 838
L2 in 11.62 13.12 14.12 17.12 22.12 26.12 31.12 33.12
(RTJ) mm 295 333 359 435 562 664 791 841
H in 16.73 19.76 20.51 24.41 34.88 36.69 40.94 50.39
(open) mm 425 502 521 620 886 932 1040 1280
W in 9.84 11.81 13.78 17.72 22.05 18.11 24.02 29.92
mm 250 300 350 450 560 460 610 760
WT BF 39 58 73 120 327 482 700 900
(Kg) BW 33 48 61 95 261 385 588 795







Copper Alloy Water Globe Valve 1/2" 250 LBS WP 300 LBS TEST FNPT 4









Brief introduction:

The globe valve is designed reference to advanced internal and international standard. The body adopt

sphere configuration, and it also has the feature of good appearance, nice function and superior quality.



Apply from CLASS150 to CLASS1500, and -29℃~425℃(steel), -40℃~550℃(stainless steel).



Using different material, the valve may works with different medium, such as water,oil,gas,steam,carbamide and other medium.
