TOBO STEEL GROUP CHINA
 |
| Place of Origin: | CHINA |
| Brand Name: | TOBO |
| Certification: | ISO |
| Model Number: | Floating Ball Valve |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | Valves are wrapped in plastic bubble sheet & in plywood boxes |
| Delivery Time: | 15-20 DAYS |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000PCS |
| Product Name: | Floating Ball Valve | Material: | SS316 |
|---|---|---|---|
| Presure: | 1,000/800psi | Size: | DN65 |
| Usage: | Oil And Gas | Temperature Of Media: | High-Pressure Temperature |
| Packaging Details: | Valves Are Wrapped In Plastic Bubble Sheet | Temperature: | -20 To 425°C |
| High Light: | Full Bore Reduced Floating Ball Valve,DN100 Floating Ball Valve,2 Inch Floating Ball Valve |
||
2 Inch Full Bore Reduced Floating Ball Valve Wafer Type DN100
| Name: | 2 Inch Float Valve | Wafer Type: | Wafer Type |
|---|---|---|---|
| Size: | DN15 ~DN100 | Pressure: | 150lbs~2500lbs/JIS 10K~20K /PN16~PN160 |
| Standard: | NACE | Temperature: | -10~120 C |
| Body: | SUS304 / SUS316 | Application: | Petroleum , Chemistry |
| High Light: |
Full Bore Floating Ball Valve,Wafer Type Floating Ball Valve,DN100 Floating Ball Valve |
||
Wafer Type 2 Inch Float Valve , Full Bore And Reduced Copper Ball Float Valve
2 Inch Float Valve Application
Fluid and pipeline transportation, Petroleum industry, Chemical and metallurgy, Medicine and Food industry
2 Inch Float Valve Introduction
Body:SS316
Ball:S316/SS316L
Seat : PTFE
Size : 1/2" # 800SW
Operation:Lever
NACE
2 Inch Float Valve Main part & material
| Part name | Material |
| body | WCB,ZG1Cr18Ni9Ti,CF8 |
| ball | 1Cr18Ni9Ti 304,316 |
| stem | 1Cr18Ni9Ti 304,316 |
| seal ring | Polytetrafluoroethlene(PTFE) |
| packing | Polytetrafluoroethlene(PTFE) |
| DN | G | B | L | H | A |
| 6 | 1/4" | 8 | 65 | 57 | 98 |
| 10 | 3/8" | 10 | 65 | 57 | 98 |
| 15 | 1/2" | 15 | 75 | 68 | 125 |
| 20 | 3/4" | 20 | 85 | 70 | 125 |
| 25 | 1" | 25 | 95 | 80 | 145 |
| 32 | 1-1/4" | 32 | 110 | 84 | 145 |
| 40 | 1-1/2" | 38 | 125 | 93 | 205 |
| 50 | 2" | 50 | 150 | 100 | 205 |
| 65 | 2-1/2" | 64 | 175 | 142 | 250 |
| 80 | 3" | 76 | 216 | 155 | 265 |
| 100 | 4” | 100 | 260 | 172 | 300 |
Technical Specification
| Nominal pressure(Mpa) | PN | 2.5,4.0,6.4 |
| Strength testing pressure(Mpa) | PT | 3.8,6.0,9.6 |
| Low pressure seal test(Mpa) | 0.6 | |
| High pressure seal test(Mpa) | 3.0,4.8,7.6 | |
| Applicable medium | water, oil, gas, nitric acid, acetic acid | |
| Applicable temperature | -40～180℃ | |
Feature:
- Anti-blowout Structure of Valve Stem
When medium pass through the valve, the pressure in valve body may possibly
push the stem out, or when the valve is in repair, if there is pressure in the middle
cavity, the stem or medium seems to easily fly out upon disassembling the valve,
which can cause injures to human beings,
To prevent the possibilities, a dummy club is packing and thrust bearing are burnt
or packing is damaged due to other causes, the pressure of medium in valve body
will make the dummy club of valve stem in close contact with the upper seal face of
valve body.
Thus to prevent medium leaking out from the damage packing position.
- Reliable Seal Structure
The seat is made of PTFE. Because the contact area between seat and the ball will
becomes more high with rising of pressure of the middle cavity,
Small Resistance ball valve has the smallest resistance of all the valve, in the case
of reduced bore, the resistance is little still.
- Prompt switch
The ball valve circumrotates in 90°,It work quickly to open or close.
Specifications:
Technical Specification
- Nominal diameter: 1/2”-25”
- Applicable Temperature: -29℃～425℃(steel) -40℃～550℃(stainless steel)
- Nominal pressure: 150lbs, 300lbs, 600Lb,900lbs,1500lbs PN16/25/40/64/100/160, JIS 5K /10K/20K
- Applicable Medium: water ,gas,oil,and other causticity medium.
Applications Standard
- Manufacture standard : API 608/ DIN/ BS/JIS
- Face to face dimension: ANSI B 16.10,API 6D/ DIN/ BS/JIS
- Flange dimension: ANSI B 16.5 MSS-SP-44/ DIN/ BS/JIS
- Test: API 598 API 6D/ DIN/ BS/JIS
Top entry ball valves are available in size 2~24”ANSI class rating 150 to 1500 and temperature ratings of -46 to 250 . A ll meet the fire safe requirement of BS 6755 and API 6FA.
The top entry trunnion supported design and unique seat retraction technique gives the convenience of in-line repair or replace valve internal components without dismantling it from pipe line.
Because each ball seat shuts off the line fluid independently on the upstream side, so this series ball valves are suitable for double block and bleed application.Secondary sealant injection system for stem and seat is provided for emergency stop of accidental seat or stem leakage.
Anti-Static Device
Blow-out Proof Stem
Fire Safe Design
Emergency Sealant Injector
Top entry ball valve is mainly applicable for pipeline and industry system such as petroleum, chemical engineering and nuclear power plants. Its body adopts an integrated design, reducing leak points. Its seat design is available for either soft or hard seal, easy for maintenance. It has a top entry and on line maintenance function. It has a lot of advantages, such as small fluid resistance, simple structure, small volume, light weight, reliable sealing, convenience for operation and maintenance, open and close quickly, as well as start and close flexibly.
Its most difference from common ball valve is that its maintenance can be made on pipe line and without dismounting from the pipe line. The back space seat structure is adopted for the seat and the rear portion of seat retainer is oblique angle to prevent accumulation of impurity from affecting back space of seat.
It's featured by its small torque and reliable seal; and unlike common ball valve types, its seat with a spheroidal structure can adjust the seal position automatically.
Design and manufacture standard: ASME B16.34, API608, API6D and BS5351
End flange: ASME B16.5
Butt Weld: ASME B16.25
Inspection and Testing: API598
Face to face : ASME16.10 and DIN3202
Fire Safe Test : API 607/API 6FA
|
PART NAME |
MATERIAL |
|
BODY/BONNET |
WCB,LCC,LCB,CF8,CF8M,CF3,CF3M |
|
BALL |
WCGB+HCr,A105+HCr,2Cr13,304,316,304L,316L |
|
STEM |
2Cr13,304,316,304L,316L |
|
SEAT |
PTFE,PPL,NYLON 101 |
| SPECIFICATIONS FOR STEEL GLOBE VALVES | |
|
Pressure rating and size: |
PN10,PN25,PN40,PN64,150L-600LB |
| DN40 to DN600 | |
| 1-1/2"~24" | |
| Material: | Body : A216-WCB,A325-LCB,A217-WC6,CF8,CF8M |
| Disc : A105+13Cr, SS304, SS316 | |
| Stem : A182+F6a,A182-F6a | |
| Bonnet :A216-WCB,A325-LCB,A217-WC6,CF8,CF8M | |
| Operated type | Handwheel |
| Structure: | stopcock for water |
| Flange connection: | ASME B16.5,EN1092 |
| Butt-weld ends: | ASME B16.25 |
| Medium: | W.O.G |
| Temperature: | -20 to 425°C |
A Ball valve is a quarter-turn rotary motion valve that uses a ball-shaped disk to stop or start the flow.
It resembles a plug valve in many ways. When a port in the ball is in line, it allows flow whereas when you
rotate the valve 90 degrees, solid part of the ball stop the flow.
Most ball valves are of the quick-acting type, which requires a 90° turn of the valve handle to operate the valve.
But in case large size valve which required considerable force to open or close the valve, the gear-operated
actuator is used. With this arrangement, a small handwheel is enough to operate a fairly large valve.
In this article, I have covered following types of Ball Valves that used in piping.
Floating
Trunnion Mounted
3 Way
Top entry
Side entry or split body
Three-piece body
Applications of the Valve
It can be used in different types of fluid services as an on-off stop valve that provides bubble-tight shutoff.
It can be used in air, gaseous, and vapor services as well as hydrocarbon services.
Metal seated valves can be used in high-pressure & temperature applications.
it is widely used with instrument tubing to connect instruments.
Advantages
It is quick to open and close type that provides bubble-tight reliable sealing in high-pressure temperature applications.
It is smaller and lighter than a gate valve of the same size and rating.
Several designs of ball valves offer the flexibility of selection so that you can choose the valve that suits your requirements.
Easy to operate and Cost-effective maintenance.
Features:
1.Forged ball
2.Anti-fire safe design
3.Anti-static device
4.Free leakage of body Sealed construction
5.Low torque in operation
6.Double block&bleed(DBB)
7.Emergency sealing
8.Extension stem at your choice
9.Automatic body cavity relief
10.Various driving types: gear, lever, electric, hydraulic, pneumatic
Standards Compliance
Design and manufacture: ANSI B16.34, API 608, API 6D, BS5351
Face to face dimensions: ANSI B16.10, API 6D
Flanged connection: ANSI B16.5, ANSI B16.47
Butt welded: ANSI B16.25
Fie-safe: API 607, API 6FA
Test and inspection: API 598, API6D
Packaging Details
Valves are wrapped in plastic bubble sheet & in plywood boxes
Port:China
Lead Time :
| Quantity(Sets) | 1 - 100 | >100 |
| Est. Time(days) | 25 | To be negotiated |
Types of Ball Valves:
Although ball valves can be divided into many types based on the functionality, their major two categories are given below:
Floating Ball Valve:
A floating ball valve does not have any anchor for holding the ball. However, there is a stem that is attached to the ball.
Due to this reason the fluid freely moves the ball downwards according to the pressure of the flow. A floating ball valve
is considered a great choice for regulating the flow of the valve.
Trunnion Ball Valve:
Unlike the floating ball valve, trunnion ball valve comes with an anchor on both sides of the ball. This additional support
provides pivot to the ball and helps contain the huge flow. Due to this reason, trunnion ball valves are very popular for the
applications, which involve the flow of high-pressure valves.
